Disc Shape Fermentation Equipment

Disc Shape Fermentation Equipment
Disc Shape Fermentation Equipment

The MYPJ model disc fermenter is an efficient modern fermentation equipment for strains which require strict hygienic conditions. The disc Shape fermentation machine controls every parameter setting automatically for an accurate final product.

Features
1. Fully automatic, controlled by a Programmable Logic Controller and touch screen. Easily change parameters and record data.
2. Temperature, humidity, air pressure and time can all be controlled.
3. Quality sealing prevents any material from leaking during the process.
4. Open center is easy and convenient to keep clean.
5. Design of the main transmission and lift system incorporates automatic frequency conversion for easy adjustment of parameters.

Disc Shape Fermentation Equipment
Disc Shape Fermentation Equipment

Parameters

Model Starter propagation area (m2) Disc diameter (mm) Starter propagation thickness (mm) Power (KW)
MYPJ600 27.36 Φ6000 ≥ 600 40
MYPJ700 37.9 Φ7000 48
MYPJ800 49.7 Φ8000 66
MYPJ1000 77.3 Φ10000 84
MYPJ1100 93.8 Φ11000 108
MYPJ1200 112 Φ12000 116
MYPJ1300 131 Φ13000 130
MYPJ1500 175 Φ15000 150
MYPJ1700 220 Φ17000 189
