Flaking Mill

Flaking Mill
Flaking Mill
Flaking Mill

The MZPG flaking mill is an efficient seed processing equipment for pretreating soybeans, cotton seeds, tea seeds, corn, and other seeds and kernels. Ideal for flaking and pressing, our oilseed flaker extracts the maximum amount of oil from pressed seeds, making the most of your raw materials.

Features and Characteristics
1. Adjustable roll gap mechanism prevents interference by automatically adjusting both ends precisely for minimum gap (patented technology).
2. Rail bearing housing facilitates precise positioning of rolls and easy dismantling.
3. Anti-static brush on both sides of the main shaft in the working chamber prevents oil from leaking for a cleaner working environment.
4. Design of tooth belt with hydraulic automatic tensioning ensures optimal driving efficiency. (Patent)
5. Automatic tensioning device for the driving belt maintains constant belt tension for good driving efficiency.
6. Heavy duty magnet at feeding point moves parallel to the feeding gate and flow of material, efficiently picking up any iron and protecting the rolls.

Flaking Mill
Flaking Mill
Flaking Mill
Flaking Mill


Model MZPG60x50 MZPG80x210
Capacity (t/d) 300 500
Roll Dimensions 600x1500(mm) 32x84(in)
Main Motor Power (kw) 90 160
Flake Thickness (mm) 0.25~0.35 0.25~0.35
Spreading Motor Power (kw) 1.1 1.1
Feeding Motor Power (kw) 0.37 0.75
Pump Motor Power (kw) 0.55 15
Dimensions (L*W*H)
398x230x226 370x372x202
