Submerged Scraper Conveyor
Our YMC series submerged scraper conveyor is self-cleaning slanted continuous conveying equipment used for premixing and transporting powder, granular material, and sheet material in oil factories and feed mills. The elevated conveyor also carries semi-finished products and finished grain products in processing plants.
Features
1. The scraper conveyor adopts wear-resistant materials for high strength, reducing noise and prolonging service life.
2. The unique seal structure of nose and tail gives the F-drag conveyor outstanding performance.
3. Includes standard gear such as an access port, stall sensors, axle temperature monitor, etc.
4. The cranked link chain on the conveyor chain has good mechanical properties and works even in harsh operating conditions.
Parameters
| Type/ Parameter | YMC Series Submerged Scraper Conveyor | ||||||
| Conveying Capacity (m^3/h) |
Chain Speed (m/s) |
Groove Width (mm) |
Loading Height (mm) |
Conveying Chain Pitch (mm) |
Major Seal Material | ||
| Ordinary type (series of T) |
13x020 | 23~58 | 0.25~0.63 | 200 | 130 | 78.1 | NBR |
| 16x025 | 36~90 | 0.25~0.63 | 250 | 160 | 78.1 | NBR | |
| 20x032 | 57~145 | 0.25~0.63 | 320 | 200 | 101.6 | NBR | |
| 16x025 | 36~90 | 0.25~0.63 | 250 | 160 | 101.6 | NBR | |
| 25x040 | 90~226 | 0.25~0.63 | 400 | 250 | 101.6 | NBR | |
| 25x050 | 112~280 | 0.25~0.63 | 500 | 250 | 120.9 | NBR | |
| 25x063 | 140~350 | 0.25~0.63 | 630 | 250 | 120.9 | NBR | |
| 32x050 | 144~360 | 0.25~0.63 | 500 | 320 | 120.9 | NBR | |
| Ordinary heat type (series of N) |
32x063 | 180~450 | 0.25~0.63 | 630 | 320 | 120.9 | NBR |
| 25x050 | 112~280 | 0.25~0.63 | 500 | 250 | 153.67 | NBR | |
| 25x063 | 140~350 | 0.25~0.63 | 630 | 250 | 153.67 | NBR | |
| 25x080 | 180~450 | 0.25~0.63 | 800 | 250 | 153.67 | NBR | |
| 32x050 | 144~360 | 0.25~0.63 | 500 | 320 | 153.67 | NBR | |
| 32x063 | 180~450 | 0.25~0.63 | 630 | 320 | 153.67 | NBR | |
| Resistant type (series of M) |
32x080 | 230~580 | 0.25~0.63 | 800 | 320 | 153.67 | NBR |
| 32x100 | 280~720 | 0.25~0.63 | 1000 | 320 | 153.67 | NBR | |
| 32x120 | 340~870 | 0.25~0.63 | 1200 | 320 | 153.67 | NBR | |
| 32x140 | 400~1000 | 0.25~0.63 | 1400 | 320 | 153.67 | NBR | |
| Hermetic type | 32x160 | 460~1150 | 0.25~0.63 | 1600 | 320 | 153.67 | NBR |
| 40x100 | 360~900 | 0.25~0.63 | 1000 | 400 | 153.67 | NBR | |
| 40x120 | 430~1050 | 0.25~0.63 | 1200 | 400 | 153.67 | NBR | |
| 40x140 | 500~1250 | 0.25~0.63 | 1400 | 400 | 153.67 | NBR | |
| 40x160 | 570~1450 | 0.25~0.63 | 1600 | 400 | 153.67 | NBR |
|
